LED TRI-FOLD SCREEN

  • LED tri-fold screen with GOB process
  • Pixel pitch options: 1.25/1.53/1.86/2/2.5
  • LED Lamp: Nationstar/ Kinglight/Rayshine
  • System: Huidu ( Novastar/ colorlight also optional)
Call us

+86 135 4920 2705

Email us

977molly@gmail.com

Our specialty

1, Turnkey solutions: product sourcing, installation, and long‑term maintenance in one packag

2, Custom-made LED displays + free on‑site design and layout consultation.

3,Rapid 7‑10 days production and dedicated project management from order to handover.

NameItemSFT-2.5SFT-1.86SFT-1.53SFT-1.25
Module parametersPixel spacing2.5mm1.86mm1.538mm1.25mm
Resolution128*(h)64172*(h)86204*(h)104256*(h)128
 Module Size(w)320*(h)160mm(w)320*(h)160mm(w)320*(h)160mm(w)320*(h)160mm
Protective processGOBGOBGOBGOB
Optical parametersBrightness(CD/㎡)600CD650CD700CD750CD
Gray level14-16BT
adjustable
14-16BT
adjustable
14-16BT
adjustable
14-16BT
adjustable
Best view distance4-20M3-20M2-20M1.5-20M
View agle160°160°160°160°
Contrast ratio8000:01:008000:01:008000:01:008000:01:00
Communication parametersSynchronous/AsynchronousBoth supported
Control methodAPP/USB /Ethernet port/4G remote control
 InterfaceJS485*1  WIFI*1 USB*1  HDMI*2
SpeakerBuilt-in speaker50*12mm*2PCS
Audio interface3.5 Audio Interface/Supports External Amplifier
Performance processingDrive modeConstant current drive
Frame Frequency60HZ
Refresh rate≥3840HZ
Using parametersTypical lifespan values50000H
Working temperature range-40—50℃
Operating humidity range10-80% without condensation
